The UltraX-20 Amplifier is a rugged source of RF power, useful for ultrasonics, Neuromodulation equipment and general laboratory applications. The UltraX-20 represents E&I’s commitment to providing RF power amplifiers of the highest quality, durability and ruggedness.
The E&I UltraX-20 RF Power Amplifier produces 20 Watts of class A linear power output over the entire frequency range from 100 KHz to 2 MHz. It has very low harmonic distortion along with low IMD products. The power gain is rated at 40 dB with a typical gain flatness of +/- 1.5 dB.
The E&I UltraX-20 RF Power Amplifier is compatible with most signal generators, frequency synthesizers, sweep generators and other laboratory signal sources. It accurately reproduces all waveforms within its power and frequency ranges: AM. FM, SSB, pulsed and other complex modulation schemes.
The E&I UltraX-20 RF Power Amplifier is built to withstand a 13 dBm input (1.0 Volt RMS) for any VSWR load condition. The internal switched mode power supply is very conservatively rated, in order to facilitate operation over a large range of line conditions and temperatures. The forced air cooling provides for low internal temperatures, providing long term reliability. The RF power is delivered by rugged DMoS FETs, de-rated to provide for excellent MTBF figures.
