The PVM-1001 can achieve zero to -950 V or zero to +950V in less than 10 ns (Rise Time). This adjustable pulsed voltage source is capable of providing pulse widths from 55 ns to 10,000 ns with a standard frequency range up to 1 MHz. The PVM-1001 can also provide a 5 MHz burst. The module is designed for a 50 ohm resistive load.
The output pulse width and frequency are controlled by an external trigger source. The PVM-1001-N requires an external negative high voltage supply. Two models are available, one for positive and another for negative output.
The rear panel of the PVM-1001 has connectors for the high voltage input and pulsed high voltage output. The front panel has an SMB connector for triggering the instrument.
