Digitizers pci express
PCI Express digitizers are mostly used in laboratory environment. The integration into your communication network, is very easy. A standard Windows or Linux computer with at least one PCI Express slots is the unique requirement.
PCI Express digitizers will transform your desktop on a very high performance recording system, with high speed transfer between the digitizer and the computer, up to 5Gbytes/Sec, for further processing. The PCI Express bus is a point to point connection allowing full speed for every single slot.
The PCI Express bus is available with 1 lane (x1), 4 lanes (x4), 8 lanes (x8) and 16 lanes (x16). GaGe and Signatec digitizer’s require 8 lanes PCI Express bus to allow data transfer at full speed.
-
Cobra Express
2 GS/s, 8-Bit High speed data acquisition board
- 2 GS/s Digitization on one channel
- Simultaneous 1 GS/s
-
CobraMax Express
PCI Express, 4 GS/s, 8-Bit High speed data acquisition board
- 1 or 2 digitizing channels
- 4 GS/s maximum sampling
-
EON Express
12-Bit, high speed data acquisition boards
- 1 Channel at 6 GS/s or 2 Channels at
-
PX14400A
400 MS/s, 14-Bit, PCI Express high speed data acquisition board
- 2 AC-Coupled Analog Channels at up to 400 MHz
-
PX14400D
400 MS/s, 14-Bit PCI Express high speed data acquisition board
- 2 DC-Coupled Analog Channels at up to 400 MHz
-
PX1500-2
3GS/s 8-Bit, PCI express high speed data acquisition board
- 1 AC or DC Coupled Analog Channel at up
-
PX1500-4
3GS/sec, 8-Bit, PCI Express high speed data acquisition board
- 2 AC or DC Coupled Analog Channels at up
-
RazorEdge Express
16-Bit / 14-Bit, 2-CHs @ 250 MS/s, PCIe Gen3 x8 Digitizer
- 16-Bit or 14-Bit Vertical A/D Resolution with 2 Digitizing
-
RazorMax Express
16-Bit, 4-CHs or 2-CHs @ 1 GS/s, PCIe Gen3 x8
- 16-Bit Vertical A/D Resolution with 4 or 2 Digitizing
-
RazorPlus Express
16-Bit 500MS/s High Speed data acquisition Digitizers PCI Express
- 16-Bit or 14-Bit Vertical A/D Resolution with 2 Digitizing
-
Sabre Express
16-Bit, 4-CH @ 250 MS/s, PCIe Gen3 x8
- 16-Bit A/D Resolution with 4 Digitizing Input Channels
- 250
-
VR8042
2 Channels, 12-bit, 10GS/s, DC-4GHz digitizer
- Dual channel 12-bit ADC, 10 GSa/s per channel
- DC
